Hysterosalpingogram findings among women with infertility in Ogun State, Nigeria

  • A A Olatunji Department of Radiology, Olatunji Onabanjo University Teaching Hospital, Sagamu.
  • O E Jagun Department of Obstetrics and Gynaecology Olabisi Onabano University Teaching Hospital Sagamu
  • O O Toyobo
  • O A Ashaolu
  • O A Adekoya
Keywords: Findings, Hysterosalpingogram, Imaging technique, Infertility


Background: Infertility is a relatively common health challenge in the society with social and psychological consequences. Hysterosalpingogram (HSG) is traditionally used to ascertain some of the causes of infertility. The use of ionizing radiation and contrast media injection with the possibility of complications, make new imaging modalities preferable, especially when in-vitro fertilization is being considered as a management option.

Objective: To describe the pattern of the cervical, uterine, tubal and adnexial abnormalities causing infertility as detected by HSG in a tertiary health care institution, and demonstrate the prospects of retaining Hysterosalpingography in the investigation of female infertility.

Methods: The HSG and reports of 124 patients referred to the Radiology Department of a tertiary health facility between January, 2013 and June, 2014, at a tertiary healthcare institution, were reviewed for abnormalities in the cervix, uterus, the fallopian tubes and adnexial structures.

Results: Secondary infertility was the commonest indication for the procedure among in 66 of the 124 HSG reviewed. Pathologies in the cervix were found in 66 (51.6%) cases, of which the most frequent abnormality was cervical fibrosis in 59.4% (36/66) cases.  Uterine abnormalities were found in 71.7% (89/124) cases, with uterine fibroid occurring in 82% (73/89) of these cases. Pathologies in the Fallopian tube occurred in 68 (54.8%) cases, with bilaterally blocked tubes occurring most frequently in 32.4% (22/68). Twenty-seven of the 68 cases (39.7%) with tubal abnormalities were aged 20-29 years.

Conclusion:  Secondary infertility was the commonest indication for HSG in the study, while uterine fibroid, cervical fibrosis and bilaterally blocked tubes were the most prominent findings in descending order of frequency. Therefore, caution should be exercised in managing pelvic infections, inflammations, diagnostic dilation and curettage and post-abortal and post-surgical periods in order to reduce the risk of fibrosis.

Author Biography

A A Olatunji, Department of Radiology, Olatunji Onabanjo University Teaching Hospital, Sagamu.
Department of Radiology, Senior Lecturer


McLaren JF. Infertility evaluation. Obstet Gynecol Clin North Am 2012; 39: 453-63.

Theodore A, Baramki MD. Modern trends in hysterosalpingography. Fertil Steril 2005; 83:1595-606.

Okafor CO, Okafor CI, Okpala OC, Umeh E. The pattern of hysterosalpingographic findings in women being investigated for infertility in Nnewi, Nigeria. Niger J Clin Pract 2010; 13: 264-67.

Okonofua FE. Infertility in Sub-Saharan Africa. In: OkonofuaF, Odunsi K.(eds). Contemporary Obstetrics and Gynaecology for Developing Countries. Benin-City, Nigeria, WHARC. 2003: pp 128-156.

Sadow CA, Sahni VA. Imaging female Infertility. Abdom Imaging 2014; 39: 92-107.

Kdous M. Hysterosalpingography in the assessment of tubal patency. La Tunisie Medicale 2006; 84(8): 520-25.

Marci R, Marcucci I, Marcucci AA, Pacini N, Salacone P, Sebastianelli A, et al. Hysterosalpingocontrast Sonography (HyCoSy): evaluation of the pain perception, side effects and complications. BMC Med Imaging 2013; 13:28.

De Felice C, Rech F, Marini A, Stagnitti A, Valente F, Cipolla V, et al. Magnetic resonance hysterosalpingography in the evaluation of tubal patency in infertile women: an observational study. Clin Exp Obtet Gynecol2012; 39: 83-8.

Dudiak CM, Turner DA, Patel SK, Archie JT, Silver B, Norusis M. Uterine leiomyomas in the infertile patient: preoperative localization with MR imaging versus US and hysterosalpingography. Radiology 1988; 167: 627-30.

Ait Benkaddour Y, Gervaise A, Fernandez H. Which is the method of choice for evaluating uterine cavity in infertility workup?. J Gynecol Obstet Bio Reprod 2010;39: 606-13.

Bosteels J, Kasius J, Weyers S, Broekmans FJ, Mol BW, D’Hooghe TM. Hysteroscopy for treating subfertility associated with suspected major uterine cavity abnormalities. Cochane Database Syst Rev. 2013;1: CD009461. DOI: 10. 1002/14651858. CD009461.pub2.

Malek-Mellouli M, Gharbi H, Reziga H. The value of sonohysterography in the diagnosis of tubal patency among infertile patients. Tunis Med 2003; 91: 387-90.

Daaloul W, Ouerdiane N, Masmoudi A, Ben Hamouda S, Bouguerra B, Sfar R. Epidemiological profile , etiological diagnosis and prognosis of uterine synechias: report of 86 cases. Tunis Med 2012; 90: 306-10.

Kiguli-Malwadde E¹, .Byanyima RK. Structural findings at hysterosalpingography in patients with infertility at two private clinics in Kampala, Uganda. Afr. Health Sci. 2004; 4: 178-81.

Imo AO, Sunday-Adeoye I. Radiological assessment of the uterus and fallopian tubes in infertile women in Abakaliki , Nigeria. Niger J Clin Pract 2008; 11: 211-15.

Malhotra N, Sood M. Role of hysteroscopy in infertile women. J Indian Med Assoc 1997 ; 95: 499-525.

Hatasaka H. An efficient infertility evaluation. Clin Obstet Gynecol 2011; 54: 644-55.

Bukar M, Mustapha Z, Takai UI, Tahir A. Hysterosalpingographic findings in infertile women: a seven year review. Niger J Clin Pract 2011; 14: 168-70.

Ibekwe PC, Udensi AM, Imo AO. Hysterosalpingographic findings in patients with infertility in South eastern Nigeria. Niger J Med 2010; 19: 165-67.

Bello TO. Tubal abnormalities on hysterosalpingography in primary and secondary infertility. West Afr J Med 2006; 25: 130-33.

Kroon B, Johnson N, Chapman M, Yazdani A, Hart R; Australasian CREI Consensus Expert Panel on Trial evidence(ACCEPT) group. Fibroids in infertility—Consensus Statement from ACCEPT (Australasian CREI Consensus Expert Panel on Trial evidence). Aust N Z J Obstet Gynaecol 2011; 51: 289-95.

Ogedengbe OK. Uterine Fibroids. In: Okonofua F and Odunsi K. (eds) Contemporary Obstetrics and Gynaecology for developing Countries..Benin-City, Nigeria. WHARC. 2003: pp 202-213.

Cisse R, Louge C, Ouegraogo A, Thieba B, Tapsoba T, Ouedraogo CM, et al. Feature of hysterosalpingography performed in Burkina Faso. J Radiol 2003: 83: 361-41.

Nwankwo NC, Akani CI. Pattern of Hysterosalpingographic findings in infertility in Port Harcourt. West Afr J Radiol 2005; 12: 15-19.
